WEBGPU FORWARD+ RENDERER
WEBGPU · TYPESCRIPT · GPU LIGHT CULLING
A real-time renderer comparing naive forward, Forward+ and clustered deferred pipelines. Thousands of dynamic lights, compute-driven clustering, render bundles and bloom expose the performance tradeoffs behind modern WebGPU rendering.
WebGPU
Forward+
A real-time renderer built around clustered light assignment, with forward and deferred paths sharing one WebGPU scene pipeline.
One scene.
Three paths.
The renderer separates scene preparation from lighting so the same camera, materials and geometry can move through direct forward shading, clustered Forward+, and clustered deferred shading.
Clusters before
shading.
A compute pass divides the camera frustum into screen-space tiles and depth slices. Lights are assigned once to the clusters they touch; the shading pass reads only the relevant list.
Renderer
anatomy.
The project is organized as a sequence of explicit GPU passes. Each stage owns a clear resource boundary, making the lighting paths easy to compare and extend.
Scene pass
Loads meshes and materials and prepares shared geometry buffers.
Cluster compute
Builds per-cluster light lists before surface shading begins.
Lighting paths
Switches between forward and deferred implementations.
Post process
Composes the lit frame through a fullscreen compute stage.
